5 AXIS CNC HOBBING MACHINE
Dimension :
Dimension
Max workpiece dia 400、Max Pitch module 7、Axial feed travel 300、max helix angle 45°、max hob shif travel 150、center distance between hob&table 35~305、table size 460φ、hob spindle RPM10~500rpm、FANUC 10M、maachine weight 9800kg
5 AXIS CNC HOBBING MACHINE
Dimension :
Dimension
Max workpiece dia 400、Max Pitch module 7、Axial feed travel 300、max helix angle 45°、max hob shif travel 150、center distance between hob&table 35~305、table size 460φ、hob spindle RPM10~500rpm、FANUC 10M、maachine weight 9800kg
5 Axis CNC Gear hobbing machine
Dimension :
Dimension
Max workpiece dia 130、Max module 3、FANUC 160i-M、Axial 5、Max axial slide travel250、Hob swivel angle ±45°、Max hob speed 3000rpm、Max workspindle speed 1000rpm、Max hob dia 80、Max hob length total length170/245、Max hob shift travel 170、Hob drive 14KW、Table surface dia 160、Machine weight 11000KG、Auto Magazine Feed Attachment
5 Axis CNC Gear hobbing machine
Dimension :
Dimension
Max workpiece dia 130、Max module 3、FANUC 160i-M、Axial 5、Max axial slide travel250、Hob swivel angle ±45°、Max hob speed 3000rpm、Max workspindle speed 1000rpm、Max hob dia 80、Max hob length total length170/245、Max hob shift travel 170、Hob drive 14KW、Table surface dia 160、Machine weight 11000KG、Auto Magazine Feed Attachment
Gear hobbing machine (High production)
Dimension :
Dimension
Max dia 150、max module 4、two auto cycle auto hob shift、auto hydraulic support lift 、support lift long size、hob spindle speed 160~530、spindle taper NT40、Main motor 5.5kw、machine weight 6300kg
HORIZONTAL HIGH SPEED GEAR HOBBING MACHINE
Dimension :
Dimension
Max dia 150φ、Max module 3 Max length 300、Auto Cycle Helix Angle ±45°、Number of Teeth(z ) 6~100、Hob Shift Travel 50
GEAR HOBBING MACHINE
Dimension :
Dimension
Max Module 16、Max dia(without support)1600、Max dia(with support)900、Table size 1350、Bore of work table 180、Main Motor 15HP、Weight 18000
GEAR HOBBING MACHINE
Dimension :
Dimension
Max diaφ380、max module 4、max hob shift 40、vertical displacement hob saddle260、center distance of hob to work 0~250、hob rpm 70~300、Table dia 325、table center bore 50、main motor 3HP、weight 2100kg
Gear shaping machine
Dimension :
Dimension
MAX DIAMETER 890φ、MAX PITCH 6
High Speed Gear shaping machine
Dimension :
Dimension
Max dia of workpiece 250、Max module 6、Max width(Ext)60、Max Width (lnt) 40、Cutter Spindle dia 85、Stroke/min 600rpm、Main Motor 2.2kw×6P、motor for Hydraulic Oil Tank 1.5kw、Net weight 3800kg、Floor Space 1200×1650
Gear shaping machine
Dimension :
Dimension
MAX DIAMETER 180φ、MAX PITCH 6
Gear shaping machine
Dimension :
Dimension
Max dia-evtermal spur gearφ180、Internal spur gear φ152、Max width 51、Max module4、Taper of cutter arbor MT5、cutter sprindle dia 85、Max cutter dia 100 Type、Distance between under surface of cutter、spindle nose and top surface of work table 95~155、work spindle bore 55、cutter strokes 225/300、340/450、500/600、weight 2500kg
Gear shaping machine
Dimension :
Dimension
MAX DIA 185φ、 MAX MODULE 6
Gear shaping machine
Dimension :
Dimension
MAX DIA 180φ、MAX MODULE 4
Gear shaping machine
Dimension :
Dimension
MAX DIA 340φ、MAX INTER DIA 540φ、MAX MODULE 5.5
Gear shaping machine
Dimension :
Dimension
Max Dia Spur 180、Max Dia Helical 165、Max Dia lnternal 139.7、Max face width external 38、Max face width internal 25.4、Max Module 6DP
Gear shaping machine
Dimension :
Dimension
Maximum pitch to be shaped module4、Maximum pitch circle diameter 180mm、Maximum face width 60mm、Range of strokes:236-630/min
Gear shaping machine
Dimension :
Dimension
Max dia185、Intemal 160、Max face width 50、Max module 6
CNC HIGH SPEED GEAR SHAPING MACHINE
Dimension :
Dimension
Max dia of pitch circle(external gear)120mm、Max dia of pitch circle(internal gear)120mm+cutter dia、Max module4、Max width of gear face 40mm、Dia of work Table 250、Number of cutter strokes 300~1500 str/m、Control：Fanuc-0m
CNC HIGH SPEED GEAR SHAPING MACHINE
Dimension :
Dimension
Max dia of pitch circle(external gear)120mm、Max dia of pitch circle(internal gear)120mm+cutter dia、Max module4、Max width of gear face 40mm、Dia of work Table 250、Number of cutter strokes 300~1500 str/m、Control：Fanuc-0m
