Surface grinding machine
Dimension :
Dimension
MAX XY:600x300
Surface grinding machine
Dimension :
Dimension
Table size 850×400、XYZ Axis Auto cycl max table longitauinal manual 950、max table cross manual 440、max distance from wheel to table surface 47.5~547.5、wheel size φ355/φ305×38×127、speed 1500/1800rpm、table chwck size 800×400×105、grinding spindle motor 3.7KW×4P、3700kg
Surface grinding machine
Dimension :
Dimension
Table size 850×350、XYZ Axis Auto cycl max table longitauinal manual 950、max table cross manual 430、max distance from wheel to table surface 47.5~547.5、wheel size φ355/φ305×38×127、speed 1500/1800rpm、table chwck size 800×400×105、grinding spindle motor 3.7KW×4P、3500kg
Surface grinding machine
Dimension :
Dimension
Max grinding length×width 500×200、vertical clearance 205mm wheel 47.5×397.5、Max weight of workpice cinclusive of magnetic chuck 200kg、Table surface length 550mm、width200mm、maximum longitudinal travel 650、cross travel 230、feeds:longitudinal move ment of table 0.3~25 m/min、Hydraulic feed 47mm、Graduation of hand wheel 0.02mm、Vertical hand feed revolution 0.001、Rapid feed 600mm/min、Grinding diameter 205φ×50.8φ、19T、3000/3600rpm、spindle motor 1.5KW/2P、Weight 1800kg
Surface grinding machine
Dimension :
Dimension
Table size 510×150、XYZ Axis Auto cycle X Axis 475mm、Max distance from wheel to table surface 310mm、wheel size 180φ×(6~25)×31.75φ、Grinder spindle motor 0.75KW×2P、machine weight 1200KG
LERTICAL AND HORIZOITAL SURFACE GRINDER MACHINE
Dimension :
Dimension
Table size：495×150、max table longitudinal feed 310、max table cross feed 150、max distance from spindle center to table surface 200、grinding wheel size 200φ×20t、grinding wheel size 160φ、machine size ：1380L×1230W×1650H、weight 2000kg
High-precision surface grinder
Dimension :
Dimension
Table size 335×140、Max table longitudinal feed 330、Max table cross feed 140、electromagnetic chunk size 305×125、Max distance from spindle conter to table surface 304.8、wheel size 178φ×12.7t×31.75φ、wheel spindle motor 1HP、Machine size 1200L×1050W×1870H、Weight 600KG
SURFACE GRINDING MACHINE
Dimension :
Dimension
Grinding length max 600mm、Grinding width max 200mm、Clamping surface of grinding table max distance between table surface and grinding spindle center 500、grinding wheel dimensions 250×25×51、grinding wheels-35 m/s
SURFACE GRINDER MACHINE (CHEVALIER)
Dimension :
Dimension
Table size700×400(L×W)、Max longitudinal travel 750、Max cross travel 450、Max grinding area(W×L)710×405、Max distance between spindle center and table 620、table clamping surface 700×400、spindle motor 5HP、Total power of motors 7.4KW
SURFACE GRINDER MACHINE
Dimension :
Dimension
Table size 460×155、magnet size 350×150
Surface grinding machine
Dimension :
Dimension
XYZ：550×400×200
DOUBLE HOUSING SURFACE GRINDING MACHINE
Dimension :
Dimension
Table size 1200×5000、Maximum passage width1200~1350、Maximum table travel 4200、Max grinding height 850、Horizontal spindle MK-20 Type 5.5KW、Vertical Spindle GV-7 Type 5.5KW、Machine Weight 23 TON
SURFACE GRINDER
Dimension :
Dimension
Fully auto、X、Y、Z、Max grinding length 600、Max grinding width 300、max distance wheel spindle center to table top 22.5~322.5
SURFACE GRINDER
Dimension :
Dimension
Max cross×longitudinal travels 340×700、Grinding surface of table 300×600、Spindle center height from table 600、spindle motor 3.7kw、spindle speed 50/60Hz
SURFACE GRINDER MACHINE
Dimension :
Dimension
Auto type tablesize 460×210、magnet size 460×210
Surface grinding machine
Dimension :
Dimension
Table600x140、XY：520x180
